- Article no.:
- PC 5366150
- Version
- with glazed door at the top, fold-out keyboard tray and component shelf
- Product description
- Secure accommodation of all PC components, from monitors, to PCs and keyboards. For ultimate ease of operation in a contemporary design. Complete protection from humidity and dirt, temperature fluctuations and unauthorized access.
- Material
- Housing, door, rear door, mounting compartment, supports: carbon steel
Handles, decorative trim panels: Plastic
Door trim panels: Aluminum
Viewing window: Single-pane safety glass
- Surface finish
- Housing and door: Dipcoat primed, powder-coated on the outside, textured paint
- General color
- RAL 7035
- Color
- Housing, door, decorative trim panels, supports: RAL 7035
Handle: RAL 7015
Monitor field, door center section: RAL 7015
- Supply includes
- Housing, door, rear door
Base Plates
Glazed door, top
Folding keyboard
Component shelf
- Dimensions
- Width: 600 mm
Height: 1,600 mm
Depth: 636 mm( Width: 23.6 ˝
Height: 63 ˝
Depth: 25 ˝ )
- Protection category IP to IEC 60 529
- IP 55
- Protection category NEMA
- NEMA 12
- Type rating according to UL 50E
- Type 1
- Type 12
- Max. keyboard dimensions (WxHxD)
- 497 x 50 x 250 mm
497 x 60 x 200 mm( 19.6 x 1.97 x 9.84 ˝
19.6 x 2.36 x 7.87 ˝ )
- Base material
- Carbon steel
- Packaging unit
- 1 pc(s).
- Net weight
- 85.5 kg
- Gross weight
- 88 kg
- PCF/VE (cradle-to-gate)
- 373.4 kg CO2 eq (Cat B)
- Information regarding the PCF class
- Category B: PCF value (cradle-to-gate) calculated approximately on the basis of the product weight and self-declared
- EAN
- 4028177959460
- ETIM 9
- EC002502
- ECLASS 8.0
- 27180501
- Product description
-
PC PC enclosure system, WHD: 600x1600x636 mm, Sheet steel, with glazed door at the top, folding keyboard, component shelf
